HA4061-AL SMPS Flyback Transformer for Capacitor Charger Controller
HA4061-AL SMPS Flyback Transformer for Capacitor Charger Controller
Features:
- Inductance is measured at 100 kHz, 0.1 Vrms.
- DCR is with the windings connected in parallel.
- Leakage inductance is for both windings of the primary with the secondary windings shorted.
- Turns ratios are with the primary and secondary windings connected in parallel.
- 3000 Vrms isolation from primary to secondary windings.
| Part number |
Inductance
at 0 A
±10%(µH)
|
Inductance
at Ipk
min (µH)
|
DCR max (mOhms)
pri
|
DCR max (mOhms)
sec
|
Leakage
inductance
max (µH)
|
Turns ratio
pri:sec
|
Ipk
(A)
|
Volt-time product typ (V µsec)
|
| HA4061-AL |
125 |
112.5 |
0.203 |
1.40 |
9.17 |
1:3 |
5.0 |
625 |
Shape and Dimensions:
Product picture:
HA4061-AL SMPS Flyback Transformer for Capacitor Charger Controller
